订货号 | 产品名称 | 品牌 | 预计出货日 | 现价 | 数量 |
---|---|---|---|---|---|
对比 SN_FE4AA1772E84 |
高速记录仪 | 感识 | 当日出货 | ¥155.00/双 |
名称: | 高速记录仪 |
品牌: | GRAPHTEC(日本日图) |
规格: | GL900 |
备注: | 高速取样调查和长时间数据收录 |
类别: | 数据采集分析→记录仪 |
产品说明 : | 高速、长时间收录的记录器 对应制品的信赖性测试 |
产品特性 : |
高速取样调查和长时间数据收录 |
规格
项 目 | 说 明 |
Item | Description |
Number of input channels | 8ch |
Type of input terminal | BNC and M3 Screw type terminal |
Method | All channels isolated, Simultaneous sampling |
Measurement range |
|
Measurement range Voltage | 20mV to 500V / F.S. (Between + and – terminals, 500 V p-p max.) |
Measurement range Temperature |
Thermocouple: K, J, E, T, R, S, B, N, W(WRe5-26) |
Measurement range Humidity | 0 to 100% ( When using optional B-530 humidity sensor is used ) |
External Input | Trigger: 1ch, Selectable between pulse and Logic: 4ch |
External output | Alarm: 4ch |
A / D converter | 16bit(out of which 14 are internally acknowledged) |
Maximum sampling interval | 10 micro-second |
Internal memory size | RAM:1 million data, 256MB Flash memory |
External memory | USB memory (1 file 2 GB) |
Calculation function | Statistics calculation, Searching function |
Display | 5.7 inch TFT color LCD |
Interface to PC | Ethernet ( 10BASE-T / 100BASE-TX ) , USB (Compatible with full speed) |
Operating environment Temperature : | 0 to 40 ℃ (15 to 40 ℃ when operating by battery ) , Humidity : 5~85 % R.H. |
Power supply Battery pack : | 2 batteries installable |
AC adapter | ( 100 to 240V AC ,50 to 60Hz ) , DC input ( 8.5 to 24V DC) |
External dimensions (approx.) | 232W x 150H x 80D mm |
Weight (approx.) | 1.1kg ( Excluding the AC adapter and battery ) |
Vibration resistance | Compatible with JIS Vibration testing methods for automobile Type 1 Class A-equivalent |
